Ruled diffraction gratings separate polychromatic light (white light) into its component wavelengths and are well suited for high precision applications, having a higher efficiency than other types of grating,

Straight and parallel grooves are ruled into the surface of an aluminium coated substrate at 300 to 1200 lines per millimetre.

Ruled diffraction gratings are used particularly in the NIR and IR range because of the larger spaces between lines, whereas visible and UV applications suffer from stray-light and ghost spectra.

For more information on our stock range of ruled diffraction gratings or to enquire about your custom requirements, please contact our technical sales team.

Data for calculation
Where G=groove density (lines/mm) and n is the order of diffraction (any integer). Blazed gratings have facets inclined at an angle b to the surface to concentrate light into the first order (n=+1). When the grating is used in the Littrow condition (retroreflection, i=i`) peak efficiency will be near the blaze wavelength shown (= (2/G) sin b)

Other wavelengths available at short notice.
Other sizes.
Other coatings, tansmission types available to order.

7 Items

Name Type Length (mm) Width (mm) Thickness (mm) Grooves/mm Blaze angle (nm) Price Buy
GDQ600300 Ruled Research Diffraction Grating 25 25 9.5 600 300
US$250.20
GDQ600500 Ruled Research Diffraction Grating 25 25 9.5 600 500
US$250.20
GDQ6001000 Ruled Research Diffraction Grating 25 25 9.5 600 1000
US$250.20
GDQ6001600 Ruled Research Diffraction Grating 25 25 9.5 600 1600
US$250.20
GDQ1200250 Ruled Research Diffraction Grating 25 25 9.5 1200 250
US$250.20
GDQ1200500 Ruled Research Diffraction Grating 25 25 9.5 1200 500
US$250.20
GDQ1200750 Ruled Research Diffraction Grating 25 25 9.5 1200 750
US$250.20
